400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill

  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
  • 400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill
Place of Origin China
Brand Name HUALONG
Certification CE ISO
Model Number XK-400
Minimum Order Quantity 1 set
Price $20,000.00 - $25,000.00/sets
Packaging Details in bulk
Delivery Time 30 days
Supply Ability 30 Set/Sets per Month

Contact me for free samples and coupons.

whatsapp:0086 18588475571

wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Diameter Of Roll(mm) 400mm Length Of Roll(mm) 1000 Mm
Core Components PLC, Bearing, Motor, Bearbox Condition New
Warranty 1 Years Key Selling Points Long Service Life
Applicable Industries Rubber Plastic Industry Machine Type Rubber Mixing Mill Machine
Model Type XK-400 XK-450 XK-560 Bush Type Bearing
Highlight

400mm Diameter Rubber Mill Mixer

,

400mm Two Roll Mixing Mill

,

Rubber Mill Mixer 37Kw
Leave a Message
Product Description

Rubber Mixing Mill Machine Rubber Mixer


Application: This 2 roller open mixing mill ensures the perfect and uniform blending of natural and synthetic rubber with other raw materials. The open mixing mill can mixall the raw materials to the desired specifications.
Structural Features: 1. This open mixing mill can be equipped with hydraulic or mechanical device which can automatically make the rubber material be mixed over and over again. So the labor intensity and mixing time can be reduced greatly.
2. The open mixing mill speed reducer is planetary speed reducer, it is low noise, high efficiency, good transfer effect.
3. To ensure the safety of staff and equipment, we install convenient button for emergency.
4. All the open mixing mills we provide to you are checked after 3-7 hours non-stop full load operation, perfect quality and low noise. Customers can use them immediately after installation.
Type XK-160 XK-230 XK-250 XK-300 XK- 360 XK-400 XK-450 XK-560 XK-550B XK-660
Working diameter of rolls (mm) 160 230 250 300 360 400 450 560/510 550 660
Working Length of rolls (mm) 320 600 620 750 900 1000 1200 1530 1500 2130
Front roll surface speed (m/min) 8.95 10.21 14.1 15.1 16.25 18.65 24.26 27.72 27.94 28.6
Friction ratio 1:1.35 1:1.19 1:1.17 1:1.25 1:1.25 1:1.27 1:1.27 1:1.2 1:1.22 1:1.24
Max. nip (mm) 4.5 7 8 10 10 10 15 15 15 15
Capacity per batch (kg) 1-2 6-10 8-15 15-20 20-25 18-35 25-50 35-50 50-60 165
Motor power (KW) 5.5 15 18.5 22 30 37 55 90 110 245
Size (L*W*H) (mm) 1380*850*1320 2800*1200*1120 3400*1500*1500 2450*1500*1550 3780*1850*1750 4350*1850*1785 5200*2380*1840 5845*2284*1978 5878*2475*2045 7465*3662*2080

Advantage:
1)Roller: made of Nickel, Chrome &Molybdenum chilled cast ironThrough centrifugal casting. Roll surface hardened layer depth isup to 10-15mm, hardness is around HS76±2.
400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 0
2)Roll bearing and seal: 8pcs double-row cylindrical roller bearing is adopted coupling with 4pcs more thrust bearing, 12pcs bearings for each machine, which could save energy consumption up to 10-15%, lubrication grease is reduced by 20-25%.2sets double-row cylindrical roller bearings for each bearing house.
400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 1
1set more thrust bearing outside the roller bearings
400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 2
3)Roll bearing lubrication: motorized auto grease pump.
4)Bearing house: made of cast steel or cast iron through anneal heating treatment and processing, with lubrication holes reserved.
anneal heating treatment bearing houses
400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 3
5)Nip adjusting device: motorized nip adjusting system, both single adjusting and multi-adjusting are available.
6)Frame: made of cast iron or fabricated through anneal heating treatment and processing.

   anneal heating treatment machine frames

400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 4

7)Bedplate: integral welding structure, made of superior U steel and constructional steel through anneal heating treatment and processing.

8)Stock guider: fixed type

9)Transmission system: complete enclosed drive, through couplings, gear reducer(single input shaft and single output shaft), driving gear and               friction gear, main motor drives the two rolls relative rotating at different speed, plasticating, mixing or sheeting could be therefore realized.

10)Roll temperature adjusting device: consisting of superior rotary joints and stainless steel pipe with drilled spraying nozzles.

11)Emergency stop and braking device: energy consumption method is used to stop the mill. There are 3-emergency stop buttons fitted on the          frames, press the button if any emergency situation occurs, the roll rotation will not exceed 1/4 circle and main motor reverse 1/4 circle thereafter within 2 seconds. Meanwhile, this mill is fitted with electrical-hydraulic brake system, which improves equipment safety ability significantly. Other safety device such as pulling rope/chest bar, foot pedal, safety protection bar are all available.

12)Stock pan: welded by superior stainless steel plate.

13 )Main motor start up: Star-delta starting.

14) Cutter device: 2pcs manual straight cutter.

400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 5

400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 6
400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 7

400mm Diameter Rubber Mill Mixer 37Kw Two Roll Mixing Mill 8
